Operator panel for inverter control MITOS VT6

This operator panel is designed to allow control and display of Toshiba and INVT inverter parameters.
It has 2*16 character alphanumeric display and 6 functional keys, on front panel with IP65 protection. Dialogue with the inverter is via RS485 interface.

The MITOS VT6 terminal is compatible with the following inverters:

• TOSHIBA:
  VF-NC3, VF-NC3E, VF-S11, VF-S15, VF-MB1, VF-FS1,
  VF-AS1, VF-PS1, VF-AS3.
• INVT:
  GD20, GD350, GD350UL, GD200A.

Different modes of inverter control can be selected:
The MITOS VT6 can be used to start/stop the motor, change the direction of rotation and frequency, or it can be used as a simple display without any control over the inverter.

MITOS VT6 is available in versions:

• Basic - Suitable for general use
• Air - Dedicated to the measurement, display and control, of pressure, velocity and flow rate of a fluid
• HVAC - Dedicated to HVAC applications

Features:

• Power supply: 9-30Vdc 50mA max. (on RJ45 connector)
• Display: 2*16-character LED-backlit LCD
• Keyboard: 6 Keys with pre-assigned functions
• Communication interface: RS485 or TTL configurable with DIP switch
• Communication protocol: Modbus RTU
• Supported languages: English, Italian, Spanish, German and Russian
• Operating Temperature: -20°C to +70°C
• Storage temperature: -30°C to +80°C
